What do the lights on my P2 Solo mean?
What do the lights on my P2 Solo mean?
From MinKNOW version 23.04 you will find the following LED patterns on your P2 Solo device.
Device ready - no flow cells inserted All five LEDs are solid white in colour
Flow cell inserted All five LEDs are solid blue in colour
Data acquisition in progress (including hardware and flow cell check) All five LEDs scroll green from left to right
Temperature warning All five LEDs flash yellow
If you observe this please check your FC/CTC heat pad, that the device is within ambient temperature range operating range (+18°C to +23°C) with 30cm clearance all around the instrument and away from direct sunlight. Then reinsert your flow cell and perform a platform QC to check the temperature control. Please reach out to customer support if you continue to see this pattern.
MinKNOW script error All five LEDs flash red
Flashing alert that indicates that the script running as encountered and error and stopped.
Please reach out to customer support if you continue to see this pattern.
Data transfer too slow between P2 solo and attached compute All five LEDs flash blue
If you see this, please ensure you’re using the included USB-C cable (‘labelled P2’) and that you’ve inserted your cable into a super speed compatible port (USB 3.0 or greater). Additionally, please ensure no unnecessary USB devices are plugged into your compute.
Script ended successfully All five LEDs are solid green in colour
