PromethION 24
Sequencing to the power of 24
Production-scale
Run up to 24 independent high-output PromethION Flow Cells.
High-performance
Superpowered GPUs for real-time insights.
Terabases of data
Ideal for high-throughput human and large-genome projects, and isoform-level transcriptomics.
Overview
Multiply your insights with PromethION 24, the production-scale nanopore sequencer that puts you in control of up to 24 high-output PromethION Flow Cells.
With superpowered onboard GPUs giving you access to terabases of data in real time, it shines in high-throughput large-genome applications. With no batching required, sequence what you need, when you need it.
Specifications
The PromethION 24 operates up to 24 high-output PromethION Flow Cells at once and is deployed with a powerful PromethION A Series tower, utilising four NVIDIA A Series GPUs for real-time data handling.
Read length
Nanopore sequencing reads the entire length of DNA or RNA fragments, from short to ultra-long (20 bp to >4 Mb).
Dimensions
Compact benchtop sequencing device with compute unit.
Sequencing Unit:
- Size (W x H x D): 590 x 190 x 430 mm
- Weight: 23 kg
Compute Unit:
- Size (W x H x D): 178 x 440 x 470 mm
- Weight: 26 kg
Suitable applications
- Large genomes or projects
- Population-scale sequencing
- Highly multiplexed small genomes or targeted regions
- Isoform-level whole transcriptomes (direct RNA or cDNA)
- Isoform-level single-cell sequencing
- Metagenome assembly
On demand
Sequence what you need, when you need it.
- Run flow cells individually or together — no more sample batching
- Each PromethION Flow Cell has approximately six times the sequencing capacity of a MinION Flow Cell
- Run multiple DNA or RNA experiments at once
- Barcode for even more samples
- Suitable for high-throughput and service labs
Accessible
- Small footprint — suitable for any lab
- Easy installation with comprehensive support
High-performance compute
Sequencing and analysis in one powerful device.
- Latest generation CPU
- 4 NVIDIA A-Series GPUs
- 60 TB SSD data storage
- 512 GB RAM
- Preloaded with Ubuntu OS and MinKNOW
Which PromethION device is right for you?
Compare how many flow cells you can run each year on a PromethION 2 Integrated (P2) or PromethION 24 (P24) device. Learn more about the PromethION 2 Integrated.
Flow cells run for 72 hours, with two full device runs per week.
